Specification | |
Model | RLP77 |
Capacity | 3500kg |
Max Rise | 2000mm surface mounted ; 1895mm recessed mounted |
Lowered Height | 105mm |
Overall Width | 2159mm |
Overall Length | 2159mm |
Runway Width | 629mm |
Width Between Platforms | 600mm |
Platform Length | 1499mm / 2159mm w/ramps extended |
Ramp Length | 330mm |
Motor / Voltage | Single Phase, 4HP,60HZ,230V |
Time to Full Rise | 39s |
Compressed Air Connection | 850-110psi |
